  • Smart Blackboard for Teaching 65" Touch Screen Digital Blackboard

    Brand: Qtenboard

    Model No.: QM-65HY

    Version:V100-A (full functionality)

    LCD size: 65 inch push pull smart blackboard

    Resolution: 3840*2160 4K resolution

    Pixel pitch: 0.372 mm x 0.372 mm

    Brightness: 350cd/m² (typ.)

    Contrast Ratio: 4000:1 (typ.)

    Color Depth: 16.7M(8bit)

    Response time: 6ms (typ.)

    Viewing area: 1428.5mm(H)×803.5mm(V)

    Android OS: Android 14.0

    LCD life: 60,000 hrs (typ.)

The Qtenboard interactive smart blackboard is a 65-inch digital blackboard built for classroom teaching and collaborative work. It combines two writing boards on the left and right with a touch panel display in the middle, so a teacher can use it as a conventional blackboard, as a touch screen blackboard, and as a display for video, images, and interactive content — without switching between separate devices.

This page explains what the digital blackboard for classroom use actually covers, how the push-pull structure works, which specifications matter for teaching, and what B2B buyers should confirm before ordering OEM or wholesale quantities.


What Is an Interactive Smart Blackboard?

An interactive blackboard in this form factor is not a single flat panel. The device consists of two writing boards on the left and right and a touch panel display in the middle. It is compatible with traditional chalk, dust-free chalk, and various water pens, so it keeps the familiar blackboard workflow while adding a high-definition display and touch interface.

In practice, that means the same surface can play educational videos, show images and animations, and accept digital annotations — combining the versatility of a digital display with the established use of a blackboard screen in the classroom.


Push-Pull Structure: How the Sliding Writing Boards Work

The 65-inch model is described as a push-pull smart blackboard. The left and right writing boards slide, while the central touch panel stays fixed. When the boards are closed, the unit reads as a conventional blackboard; when they are opened, the touch display is exposed for digital content and interaction. This is the structure that lets a sliding blackboard serve both traditional writing and digital teaching in the same wall space.

For buyers specifying a sliding blackboard with TV or display combination, the practical questions are the sliding range of the side boards, the wall-mount clearance, and whether the installation position leaves enough room for the boards to move. The unit ships with a wall mount bracket (VESA 400×500mm, 4×M8 screw), and a movable stand is available as an optional accessory.


Classroom Teaching Scenarios

A smart blackboard for teaching is typically used in a classroom where the teacher needs to move between traditional writing and digital content in the same lesson. A common workflow: the teacher opens a subject app on the display, writes and draws on the virtual whiteboard, pauses a video to explain a step, then splits the class into groups and lets students work on the board together using touch tools. Notes and annotations can be saved and shared afterwards.

The 40-point infrared touch and 1mm touch height support multiple students working at the board at the same time. The anti-glare glass and zero-gap bonding process are there to keep the surface readable under classroom lighting, and the built-in light sensor adjusts screen brightness to the environment.


65" Smart Blackboard Specifications That Matter for Teaching

SpecificationValueWhy it matters in a classroom
Display65", 3840×2160 4K, 350cd/m², 4000:1 contrastReadable text and video at classroom viewing distance
PanelBOE A+ grade panel, anti-glare glass, zero-gap bondingReduces reflection and improves touch feel
TouchInfrared touch, 40 point, 1mm touch heightMultiple students can write at the same time
SystemAndroid 14.0, Goke V100 octa-core A55, 4+32G / 8+64G / 8+128G optionalRuns teaching apps and wireless projection
Writing compatibilityTraditional chalk, dust-free chalk, water pensKeeps the familiar blackboard workflow
ConnectivityHDMI in/out, VGA, DP, USB 2.0/3.0, Type-C, RJ45, RS232Connects to existing classroom equipment
Camera / micBuilt-in camera and 8-array mic (optional)Supports remote and recorded lessons
InstallationWall mount bracket included, VESA 400×500mm; movable stand optionalFits standard classroom wall layouts

Specifications above are taken from the 65-inch smart blackboard at the time of writing. Confirm current parameters and options with the supplier before finalizing an order.


OEM & Wholesale Options for B2B Buyers

For distributors, integrators, and school-project suppliers, the OEM smart blackboard route is the relevant one. Qunmao Display was established in 2009 with a 230,000m² production base in Shenzhen and exports more than 85% of its output to over 50 countries. The product page lists customization, OEM and ODM services, boot animation customization, and optional teaching whiteboard software (1.0 Smartboard / 2.0 Qboard).

  • Panel and touch configuration. Confirm the RAM+ROM option (4+32G / 8+64G / 8+128G) and whether the built-in camera and 8-array mic are required for your project.

  • Software. Teaching whiteboard software and DMS are optional — specify these before quoting if the school or integrator needs them.

  • Accessories. Movable stand, smart pen, wireless projector, teacher's pointer, and HDMI/USB cables are optional items that affect the landed cost.

  • Certifications and QC. The product page lists CE, FCC, ROHS, ISO9001, and 3C; request current certificates rather than relying on page text.

  • Supply and after-sales. The FAQ cites 3,000–5,000 units in stock per month and a 24-hour response time; for wholesale orders, confirm spare-parts policy and warranty terms in writing.

If you are comparing this model with a standard Qtenboard touch screen blackboard, the main difference is the push-pull writing-board structure and the 65-inch classroom configuration described on this page.


Quick Buying Checklist

  • Classroom wall space and clearance for the sliding boards.

  • Whether chalk, dust-free chalk, or water pens will be used — the unit supports all three.

  • Touch requirement: 40-point infrared touch for group work.

  • System and storage option that matches the teaching software.

  • Camera/mic, teaching software, DMS, and movable stand as optional add-ons.

  • OEM branding, boot animation, and packaging requirements for wholesale orders.


Specifying a smart blackboard for a school or distribution project?

Send your classroom layout, quantity, and software requirements — we will confirm the 65-inch configuration, optional accessories, and OEM/wholesale pricing.


Send your project requirements →
