1. Product introduction

The network decoder is a network audio and video decoder designed for network video surveillance systems.. Based on the professional decoding chip, the device adopts the Linux operating system, which has good device stability and excellent decoding ability.

H.265 series products support ultra-definition 4K, H.264 series products support high-definition 1080P and below resolution network video decoding and output ; it supports multiple network transmission protocols and multiple bitstream transmission methods, and provides strong support for network video and audio decoding output, large-scale video wall decoding, splicing and segmentation picture output in video wall and other services.

2. Product characteristics

1.The equipment adopts modular structure design, a machine can be assembled by multiple modules according to the demand;

2.Single module : with 1 HDMI2.0 output;

3. Optional HDMI coding input;

4. Equipment structure: multi-module design, 1U standard chassis can be assembled with 4 modules, 2U chassis up to 12 modules, 4U chassis up to 24 modules, 8U can achieve 48 modules. If there is a need, larger models such as 12U and 16U can be customized, and multiple machines can be cascaded.

5. The device is equipped with standard interfaces such as RS485.

3. Product function ( H.265 )

3.1 Single module decoding function

◆ Support H.265 Main Profile Level 5.1, H.264 Baseline / Main / High Profile Level 5.0, MPEG4 SP L0 ~ L3 / ASP L0-L5, MJPEG / JPEG Baseline decoding ;

◆ Single support 1 channel 4K / 4 channel 1080P / 8 channel 720P / 16 channel D1 video decoding ;

◆ Support 4K, 500W, 300W, 200W, 130W and other standard video decoding ;

◆ Support PAL / NTSL and other standard formats;

◆ Support standard ONVIF access;

◆ Support RTSP direct video streaming;

◆ Support video file playback;

3.2 Single-module encoding function ( optional HDMI input, up to 1080P encoding input ) :

◆ Support 1 HDMI2.0 signal access coding;

◆ Support input signal H.264 Baseline / Main / High Profile Level 5.1 standard coding;

◆ Support MJPEG / JPEG Baseline encoding;

◆ Support coding 4K @ 30,1080 @ 60 resolution;

◆ Supports adjustable resolution and frame rate during coding;

◆ Support video stream encryption after encoding;

3.3 Single module output

◆ Support 1 HDMI2.0 interface output ; downward compatible with HDMI1.3 and other versions ;

◆ Support 1 HDMI2.0 output 3840 × 2160 @ 60fps;

◆ Single screen support maximum 25 screen segmentation;

3.4 Single module network :

◆ With a 10 / 100 / 1000Mbps adaptive network port;

3.5 Single function:

The single machine is composed of multiple modules, and the function is equivalent to the integration of multiple modules;

◆ With two USB ports (expansion, does not support the USB operation control matrix);

◆ With RS485 interface, support access to various types of module equipment ;

4. Product pictures and dimensions (H.265 standard D series box schematic)

LINK : multi-machine cascade expansion port;

USB : USB interface, reserved;

RESET : reset key, in the energized state, holding the system configuration file for more than 3 seconds will be reset to the factory value, the user configuration file will be lost, please make the corresponding backup before reset. Reset only do configuration reset, will not affect the version number and authorization.

RS485 : RS485 connection port, can access all kinds of analog equipment ;

LAN : Gigabit network port, can access the network ;

AUDIO IN & OUT : Optional ;

HDMI IN : optional, HDMI input, can access the HDMI signal for encoding ;

HDMI OUT : HDMI output, directly connected to all kinds of HDMI display devices ;
