Home  >  Products  >  Corporate Interactive Flat Panel display
Products
  • Big size 98 inch 4k uhd Touchscreen corporate interactive flat panel display

    Brand: Qtenboard

    Model No. : QM-98HY

    Version:V100-A (full functionality)

    LCD size: 98"

    Resolution: 3840*2160 4K resolution

    Pixel pitch: 0.4296mm x 0.4296 mm

    Brightness: 500cd/m² (typ.)

    Contrast Ratio: 4000:1 (typ.)

    Aspect Ratio:16: 9

    Color Depth: 16.7M(8bit)

    Response time: 6ms (typ.)

    Viewing area: 2160.8mm(H)×1216.3mm(V)

    Visual Angle: 178°(H) / 178°(V)

    LCD life: 60,000 hrs (typ.)

Big size 98 inch 4k uhd Touchscreen corporate interactive flat panel display


>>> Our Factory Video <<<


China Qunmao Factory is a leading supplier of high-quality smart digital whiteboards and interactive flat panels for education, schools, and businesses.

Our interactive flat panels are an effective tool for enhancing classroom education, teaching, and government meetings.


The Qunmao Factory is pleased to offer OEM pricing for the following sizes: We can supply the following sizes: We offer a range of sizes, including 55, 65, 75, 85, 86, 98, 100, and 110 inches. The 4k UHD smart interactive flat panel digital board for classrooms is equipped with an LCD display integrated 4K screen panel, Android OS, and an OPS PC (Intel I3, I5, I7 option). The product features a whiteboard app, annotation, record, cut-screens, zoom, and a timer. It is accompanied by free whiteboard software with a range of powerful functions, including those typically associated with science tools and lab equipment. This allows for seamless integration of teaching and learning, as well as conference activities, into the digital domain.

The software is compatible with a range of other software, including those typically associated with science tools and lab equipment.


Function summary and product advantage


1. LCD panel is for BOE brand and A+ grade panel

2. with Anti-glare glass on surface + zero gap bonding process

3. with split screen function + Wireless screen transmission, multi-screen interaction, Wireless projection and others functions

4. with light sensor, can adjust lcd screen brightness according to the environment, to fit different place use and protect eyes, and also can save power.


V100-A version 98inch interactive flat panel Description



LCD Specifications
LCD size98"
Resolution3840*2160 4K resolution
Brightness500cd/m² (typ.)
Contrast Ratio4000:1 (typ.)
Aspect Ratio16: 9
Color Depth16.7M(8bit)
Response time6ms (typ.)
Viewing area2160.8mm(H)×1216.3mm(V)
Visual Angle178°(H) / 178°(V)
LCD life60,000 hrs (typ.)
Android Specifications
CPUGoke V100, Octa-core A55 @ 1.5GHz
GPUMail-G52*4
Android OSAndroid 14.0
RAM+ROM4+32G/8+64G/8+128G (Optional)
WIFI 2.4g&5g a/b/g/n +ac
Bluetooth5.0
RJ45 100M
Video formatMPEG2-4,H.264,H.265, TS and ect
Picture formatJPG, JPEG, BMP, PNG and ect
Child locksupport
Wireless projection support
Remarks functionsupport all channel remarks
OSD languageEnglish/French/Spanish/Russian and ect
Interface (standard specs interface)
HDMI OUT*1
TF CARD*1
HDMI IN *2
LAN IN*1
LAN OUT*1
VGA*1
PC AUDIO IN*1
MIC IN*1
DP*1
LINE OUT*1
RS232*1
USB 2.0*1
TOUCH OUT (usb 2.0)*1
USB 3.0*1
2.1 Channel*1
Front side interface
TYPE C ( USB 2.0)*1
HDMI IN*1
TOUCH OUT (usb 2.0)*1
USB 3.0*2
Touch screen Specs
Touch typeInfrared touch + zero gap bonding
Touch point40 point
Touch height1mm
Camera
Built in camera and 8 Array MicOptional


Big size 98 inch 4k uhd Touchscreen corporate interactive flat panel display

Big size 98 inch 4k uhd Touchscreen corporate interactive flat panel display

Big size 98 inch 4k uhd Touchscreen corporate interactive flat panel display

Big size 98 inch 4k uhd Touchscreen corporate interactive flat panel display

Big size 98 inch 4k uhd Touchscreen corporate interactive flat panel display

Big size 98 inch 4k uhd Touchscreen corporate interactive flat panel display

Contact Us

Big size 98 inch 4k uhd Touchscreen corporate interactive flat panel display

Big size 98 inch 4k uhd Touchscreen corporate interactive flat panel display

Big size 98 inch 4k uhd Touchscreen corporate interactive flat panel display

Big size 98 inch 4k uhd Touchscreen corporate interactive flat panel display


Interactive flat panel Application Scenario


Qunmao provides one-stop commercial display engineering service. Since its establishment, qunmao has focused on providing customers with LCD splicing screen, multimedia advertising machine, touch query machine, education machine, conference tablet, terminal, etc; 5-110 inch special display products can be customized according to customer needs. It serves many projects such as public security, transportation, finance, expressway, army, border defense, customs, stock exchange, command and control center, airport, square and station, and has been recognized and praised by the industry.


98 inch interactive flat panel applications


V100-A Version 98inch interactive flat panel Technical specification



LCD brightness ajust according to environment
Size98 inch
Light sensorsupport
Power
Speaker16W*2
Standby power≤0.5W
Power supplyAC100V-240V,50-60 Hz
Power consuption (not include OPS)≤200W
Working environment
Working tempurature 0℃~40℃
Working humidity 20%~85%(no condensation)
Storage tempurature-10℃~60℃
Storage humidity10%~60%(no condensation)
Case materials
Case materialsAluminium frame + tempering glass + metal cover
Case colorBlack
Size  (W*D*H)
Unit size (W*D*H)2210.94(L)*118.30(W)*1316.16(H)mm
Packing size (W*D*H)2320(L)*230(W)*1440(H)mm
VESA Hole400*800mm, 4*M8 screw
Weight
Net Weight100±1.5 Kg
Gross Weight134±1.5kg
Standard accessories
Remote control*1
1.5m Power cable*1
Touch pen*1
Wall mount bracket*1
Antenna*2
Optional accessories
Movable standDifferent models (Optional)
Smart PenQty optional
Wireless projectorQty optional
Teacher's pointerQty optional
HDMI cable3m/5m/10m (Optional)
USB cable3m/5m/10m (Optional)
Optional functions
Motion SensorsDetects someone approaching and automatically wakes up
NFCTurn on/turn off
Lock screen/unlock screen
Air quality detectionIssue prompts and early warnings when safe concentrations are exceeded
Touch pen bring detectionQuickly open the entrance to the whiteboard and comments
FingerprintTurn on/turn off
Subwoofer20W
Teaching whiteboard software1.0 Smartboard / 2.0 Qboard (Optional)
DMSYes/No (Optional)
AI Yes/No (Optional)


Why Choose Qunmao Display?



Qunmao Display Technology Co., Ltd. was established in 2009 with a production base in Shenzhen, covering an area of 230000 square meters. The company focuses on high-tech technology enterprises specializing in the production, sales, software development, and service of LCD and central control equipment. It is a high-tech enterprise integrating intelligence, specialization, and Internet + of domestic and foreign video products, and the overall solution of domestic and foreign leading products. Solution OEM & ODM provider. Our product more than 85% export and has been receiving high reputation from customers over 50 countries and regions, such as: India, Morocco,Russia, Indonesia,USA, South Africa, Southeast Asia,pakistan, etc.


Qunmao manufacturing factory Main prdocuts include :Interactive whiteboard,interactive flat panel,splicing screens, LCD video wall,smart advertising display, smart conference panel, educational tablets, smart blackboards, Digital signage,preschool education machines, smart terminals,queue machine,etc. A high-end technology enterprise with products, it is a master in the field of high-end displays


Qunmao factory

Product equipmengt and testing

product inspection


Certifications & Exhibitions



Product certification

exhibitions

Qunmao Manufacturer Popular Products Showcase



Advertising Player


advertising player.jpg

All-in-One Interactive whiteboard


All-in-One Interactive whiteboard.jpg

Splicing screen LCD video wall


Splicing screen LCD video wall.jpg



Advantages of interactive flat panel for corporate meeting room?



1. Improved collaboration: Interactive flat panels allow multiple users to share and edit content simultaneously, making group collaboration more efficient and productive during meetings.

2. Enhanced presentations: With the ability to display high-resolution images, videos, and interactive content, interactive flat panels can make presentations more engaging and impactful.

4. Remote collaboration: Many interactive flat panels are equipped with video conferencing capabilities, allowing for seamless communication with remote team members or clients.

5. Increased efficiency: Interactive flat panels streamline meeting processes by allowing users to quickly access and display relevant information, reducing the time spent searching for materials or setting up equipment. Interactive flat panels can be integrated with other digital tools and platforms, such as interactive whiteboards and project management software, to enhance productivity and collaboration.

7. Cost-effective: While an initial investment may be required, the long-term savings on printing materials, equipment maintenance, and meeting room rental fees can offset this.


Our Services and Advantages



1. Extensive sales and manufacturing experience

2. High-tech and efficient equipment

3. Customisation, OEM and ODM Services are acceptable

4. Strictly adheres to ISO9001 standards

5. Extensive after-sales service

6. Competitive factory price and superior quality

7. All materials meet the standards

8. Exceptional customer focus and knowledge

9. Owning a production factory with a complete supply chain

10. Quick email response within 12 hours.


Packaging And Shipping



packaging and shipping


FAQ



Q: can you provide OEM services for the integrated interactive tablet?

A: Yes, it has received good support. We can customize it according to your requirements.


Q: do you have any stock?

A: We have 3000-5000 units in stock every month.


Q: is your company a real manufacturer?

A:Our company is a professional manufacturer in Shenzhen city. You are welcome to visit our factory at any time.


Q: how about the quality of the product?

A: our products have been strictly tested by QC before being delivered to customers. We sell our brand online in China's domestic market, so quality is our first priority!


Q: is this product only used in schools?

A:Our products are widely used in hospitals, schools, offices and so on.


Q: can you provide OEM services for the integrated interactive tablet?

A: Yes, it has received good support. We can customize it according to your requirements.


Q: do you have any stock?

A: We have 3000-5000 units in stock every month.


Q: is your company a real manufacturer?

A: Our company is a professional manufacturer in Shenzhen city. You are welcome to visit our factory at any time.


Q: how about the quality of the product?

A: our products have been strictly tested by QC before being delivered to customers. We sell our brand online in China's domestic market, so quality is our first priority!


Q: is this product only used in schools?

A:Our products are widely used in hospitals, schools, offices and so on.


Q: how can I trust the quality of your products?

A: We have been engaged in the business display industry for more than ten years, have independent product R & D

institutions, have strong independent R & D ability of new products, and have passed a series of domestic and international quality management system certification, 3C certification, energy saving certificate, test report, national high-tech enterprise certificate, CNAs quality certification, CE certificate, FCC certificate, ROHS certificate, biso9001 certification, ISO environmental management The product implementation standard certificate is also the designated brand in the domestic government procurement list. The market share has doubled for several consecutive years. The company has a number of invention patents, utility model patents, design patents, intellectual property rights, copyrights, etc.


Q: what is your after-sales service?

A: If you have any questions, you will get our reply within 24 hours. And provide solutions immediately.
