Home  >  Products  >  Education Interactive Flat Panel
Products
  • 9679 Chip Interactive Falt Panel 65 75 86 Inch 20 Points Touch Anti-Glare Screen Android 14.0 Built-In Whiteboard Software with Classroom Management Ai Function
    9679 Chip Interactive Falt Panel 65 75 86 Inch 20 Points Touch Anti-Glare Screen Android 14.0 Built-In Whiteboard Software with Classroom Management Ai Function
    9679 Chip Interactive Falt Panel 65 75 86 Inch 20 Points Touch Anti-Glare Screen Android 14.0 Built-In Whiteboard Software with Classroom Management Ai Function
    9679 Chip Interactive Falt Panel 65 75 86 Inch 20 Points Touch Anti-Glare Screen Android 14.0 Built-In Whiteboard Software with Classroom Management Ai Function
    9679 Chip Interactive Falt Panel 65 75 86 Inch 20 Points Touch Anti-Glare Screen Android 14.0 Built-In Whiteboard Software with Classroom Management Ai Function
    9679 Chip Interactive Falt Panel 65 75 86 Inch 20 Points Touch Anti-Glare Screen Android 14.0 Built-In Whiteboard Software with Classroom Management Ai Function
    9679 Chip Interactive Falt Panel 65 75 86 Inch 20 Points Touch Anti-Glare Screen Android 14.0 Built-In Whiteboard Software with Classroom Management Ai Function
    9679 Chip Interactive Falt Panel 65 75 86 Inch 20 Points Touch Anti-Glare Screen Android 14.0 Built-In Whiteboard Software with Classroom Management Ai Function
  • 9679 Chip Interactive Falt Panel 65 75 86 Inch 20 Points Touch Anti-Glare Screen Android 14.0 Built-In Whiteboard Software with Classroom Management Ai Function

    Size:55-110 inch

    Resolution:4K, 3840*2160

    Support OEM ODM CKD SKD

We are a professional factory that has been deeply engaged in the core materials and components of interactive whiteboards for many years.

Our core value lies in providing stable, high-quality and cost-effective raw materials, core components and flexible production cooperation models for global peer manufacturers (OEM/ODM/CKD/SKD), helping you enhance your competitiveness.


1, Core advantages: Raw material-oriented, with dual guarantees of cost and quality

     Vertical integration advantages: Possessing stable and reliable core raw materials (such as panels, touch films, optical components, key electronic components, etc.), and some key materials are self-produced

     Cost competitiveness: The materials, components and OEM/ODM services we offer to our partners have a significant price advantage, effectively reducing your BOM cost

     Quality stability: We strictly screen and control the quality of raw materials, establish a complete traceability system, and ensure that the materials input into your production line are of consistent batches and reliable in performance. This is the cornerstone of the stable quality of your products


2, Core business: Serving manufacturing peers and focusing on B2B cooperation

     Our core customer base consists of global interactive whiteboard brand owners, system integrators, and manufacturing plants seeking OEM/ODM/CKD/SKD support. It does not sell directly to C-end consumers.

     Diversified cooperation model:

     CKD/SKD supply: We offer complete bulk or semi-bulk kits to meet your needs for local assembly, cost reduction, or compliance

 with specific regional policies.

     OEM manufacturing: We strictly produce complete machines in accordance with your design, specifications and requirements

 to ensure consistent quality.

     ODM cooperation: Based on our mature platform and technology, we offer a one-stop solution from product design,

R&D to manufacturing to accelerate the launch of your products.


3,Manufacturing strength and certification: International compliance, reliable quality

     International standard certification: The factory has passed the ISO 9001 quality management system certification to ensure the

standardization of the production process and the controllability of product quality.

     Global market access support:     Familiar with the product certification requirements of the main target markets (such as CE, FCC, RoHS, REACH, KC, BIS, CCC, etc.), our products    and materials can provide corresponding certification support based on the demands of the target markets or have passed mainstream

certifications, helping your products smoothly enter the global market.


4,Value Proposition: To be your trusted "upstream partner"

  Stable supply and production guarantee: Eliminate your concerns about unstable supply of key materials and ensure the smooth operation of your production plan.

  Reduce costs and increase gross profit: Offer competitive prices to directly improve the cost and profit margin of your products.

  Simplify processes and accelerate time to market: Through CKD/SKD and OEM/ODM cooperation, reduce the complexity of your supply chain management and shorten the product time

to market cycle.

  Compliance support, smooth market: Provide certified products/materials that meet the requirements of the target market to clear your market access obstacles.

  Originating from manufacturing, we understand it better: We are in the same industrial chain as you, ensuring smoother communication and more practical solutions.

Interactive Whiteboard:9679 Chip With Ai Function and Whiteboard Software with Subjects such as Geography, Chemistry and Music etc.


Size65''75''86'' and more
Function summary and product advantage
1.  LCD panel is for BOE brand and A+ grade panel
2.  with Anti-glare glass on surface + zero gap bonding process
3.  with split screen function + Wireless screen transmission, multi-screen interaction, Wireless projection and others functions
4. with light sensor, can adjust lcd screen brightness according to the environment, to fit different place use and protect eyes, and also can save power.
LCD Specifications
LCD size65"75"86"
Resolution3840*2160 4K resolution 3840*2160 4K resolution 3840*2160 4K resolution
Brightness350cd/m² 400cd/m² (typ.)450cd/m²
Contrast Ratio4000:14000:1 4000:1
Color Depth16.7M(8bit)16.7M(8bit)16.7M(8bit)
Response time6ms 6ms 6ms
Viewing area1428.5mm(H)×803.5mm(V)1650.2mm(H)×928.3mm(V)1895.04mm(H)×1065.96mm(V)
Visual Angle178°(H) / 178°(V)178°(H) / 178°(V)178°(H) / 178°(V)
LCD life60,000 hrs 60,000 hrs 60,000 hrs
Android Specifications
CPUMEDIATEK 9679, Ouad-core A73MEDIATEK 9679, Ouad-core A73MEDIATEK 9679, Ouad-core A73
GPUMali G52-MC1Mali G52-MC1Mali G52-MC1
Android OSAndroid 14.0Android 14.0Android 14.0
RAM+ROM4+32G/8+128G (Optional)4+32G/8+128G (Optional)4+32G/8+128G (Optional)
WIFI 2.4G&5G2.4G&5G2.4G&5G
Bluetooth5.0 5.0 5.0
RJ45 100M 100M 100M
Video formatMPEG2-4,H.264,H.265, TS and ectMPEG2-4,H.264,H.265, TS and ectMPEG2-4,H.264,H.265, TS and ect
Picture formatJPG, JPEG, BMP, PNG and ectJPG, JPEG, BMP, PNG and ectJPG, JPEG, BMP, PNG and ect
USB lcoksupportsupportsupport
HDMI locksupportsupportsupport
Screen locksupportsupportsupport
Pattern locksupportsupportsupport
APK install locksupportsupportsupport
Wireless projection Support Photool, EShare, USB displaySupport Photool, EShare, USB displaySupport Photool, EShare, USB display
Remarks functionsupport all channel remarkssupport all channel remarkssupport all channel remarks
OS languageEnglish/French/Spanish/Russian and ectEnglish/French/Spanish/Russian and ectEnglish/French/Spanish/Russian and ect
Interface (standard specs interface)
LINE IN*1*1*1
LINE OUT*1*1*1
RJ45 *1*1*1
USB 2.0*2*2*2
USB 3.0*1*1*1
TYPE C *1*1*1
HDMI IN*2*2*2
TOUCH OUT *1*1*1
RS232*1*1*1
SPDIF OUT*1*1*1
Front side interface
TYPE C ( USB 2.0)*1*1*1
HDMI IN*1*1*1
TOUCH OUT (usb 2.0)*1*1*1
USB 2.0*3*3*3
Touch screen Specs
Touch typeInfrared touch + zero gap bondingInfrared touch + zero gap bondingInfrared touch + zero gap bonding
Touch point40 point40 point40 point
Touch height1mm1mm1mm
Camera
Built in camera 48MP and 8 Array MicOptionalOptionalOptional
Power
Speaker15W*215W*215W*2
Standby power≤0.5W≤0.5W≤0.5W
Power supplyAC100V-240V,50-60 HzAC100V-240V,50-60 HzAC100V-240V,50-60 Hz
Power consuption (not include OPS)≤200W≤320W≤410W
Working environment
Working tempurature 0℃~40℃0℃~40℃0℃~40℃
Working humidity 20%~85%(no condensation)20%~85%(no condensation)20%~85%(no condensation)
Storage tempurature-10℃~60℃-10℃~60℃-10℃~60℃
Storage humidity10%~60%(no condensation)10%~60%(no condensation)10%~60%(no condensation)
Case materials
Case materialsAluminium frame + tempering glass + metal coverAluminium frame + tempering glass + metal coverAluminium frame + tempering glass + metal cover
Case colorBlackBlackBlack
Size  (W*D*H)
Unit size (W*D*H)1485(L)*88.3(W)*901.8(H)mm1707.1(L)*88.5(W)*1026.7(H)mm1953.4(L)*96.5(W)*1166.6(H)mm
Packing size (W*D*H)1580(L)*205(W)*1000(H)mm1810(L)*205(W)*1150(H)mm2060(L)*205(W)*1331(H)mm
VESA Hole400*500mm, 4*M8 screw400*600mm, 4*M8 screw400*800mm, 4*M8 screw
Weight
Net Weight36±1.5 Kg50 ±1.5 Kg63 ±1.5 Kg
Gross Weight43±1.5kg58.5±1.5 Kg74.5±1.5 Kg
Standard accessories
Remote control*1*1*1
1.5m Power cable*1*1*1
Touch pen*1*1*1
Wall mount bracket*1*1*1
Antenna*3*3*3
Optional accessories
Movable standDifferent models (Optional)
Smart PenQty optional
Wireless projectorQty optional
Teacher's pointerQty optional
HDMI cable3m/5m/10m (Optional)
USB cable3m/5m/10m (Optional)
Container for CBU
40HQ (for each size)220pcs166pcs138pcs


Welcome to contact us: info@qtenboard.com;+86 15920011166


-Product Description

The advent of interactive whiteboards has redefined modern meeting experiences, delivering groundbreaking collaborative advantages for professional environments.



Whether you're a business executive, team leader, or conference participant, you'll appreciate this advanced collaboration solution. Featuring a crystal-clear 4K ultra-HD display, the interactive whiteboard ensures razor-sharp visibility for detailed data presentations and complex schematics.



With support for 40-50 simultaneous touch points, the system enables true multi-user engagement - perfect for collaborative brainstorming sessions and real-time strategy mapping. The precision 1mm writing sensor facilitates accurate annotation directly on digital documents, while the palm-erase function maintains seamless workflow during fast-paced discussions.



Enhanced with professional-grade diagramming tools, customizable templates, and seamless integration with video conferencing platforms, this solution transforms ordinary meetings into dynamic working sessions.



From agile project planning to executive decision-making, its intelligent features help streamline collaboration, accelerate consensus-building, and turn every discussion into actionable outcomes.



» Product Highlights



»Enterprise-Grade Interactive Conference Board

maintaining professional aesthetics in executive boardrooms while supporting wall-mount or mobile cart installations across spaces from huddle rooms (1-8p) to auditoriums (100+ participants).


»Next-Gen Visual Performance

True 4K Dual-Codec Display with BOE's industrial-grade IPS panel (450 and more nit brightness/178° viewing angle)


»Smart Connectivity Ecosystem

Hybrid Interface Hub:HDMI,USB2.0,USB3.0,Type C and more.

9-Way Multi-Screen Collaboration: Simultaneous display + control of laptop/tablet/cloud docs


»Dedicated Conference Computing Architecture

MediaTek and more CPU to Ensures 30+ participant video conferences with zero latency (4K@60fps HDR)


» Commercial Value


»Enhanced Meeting Efficiency & Productivity

Real-time Collaboration: Supports 40-50 multi-touch points and 9-device split-screen operation, eliminating device-switching delays and boosting decision-making efficiency by 40%+.

AI-Powered Tools: Automated meeting minutes, voice-command annotations, and task tracking reduce post-meeting documentation time by 50%, directly translating to productivity gains.



»Reduced Operational Costs

ROI on Hardware: Military-grade metal casing and modular design extend lifespan to 8-10 years, reducing maintenance costs by 60% compared to traditional projectors.

Resource Consolidation: Integrates video conferencing, document collaboration, and peripheral control, replacing whiteboards/projectors/VC systems to cut initial procurement costs by 35%.



»Empowered Hybrid Work & Global Collaboration

Zero-Latency 4K Meetings: MediaTek NPU ensures smooth 30+ participant 4K@60fps video, improving cross-border team efficiency by 55% for 24/7 multi-timezone workflows.

Native Platform Compatibility: Seamless integration with Zoom/Teams/Webex slashes IT adaptation costs and reduces staff training time by 70%.



»Elevated Client Experience

Immersive Proposal Presentations: 4K dual-codec display + AR remote annotation boosts client interaction by 200%, shortening deal cycles by 30%.

Industry-Specific Customization: Configurable chipset modules (financial data visualization/medical imaging collaboration) enable differentiated B2B service offerings.



»Quantifiable ROI Model

Per-Room Annual Value: For a 10-person mid-sized meeting room: 250 saved hours/year + ¥180,000 travel cost reduction = ROI payback period <14 months.

Enterprise-Wide Impact: 100-unit deployments accelerate cross-departmental project delivery by 45%, generating over ¥5M annual indirect revenue.



» Detail information



Inch

Length(mm)

Width(mm)

Height(mm)

G.W.

55

1277

790

89

50

65

1485

910

88

80

75

1707

1030

89

100

85/86

1953

1170

97

130

98

2210

1320

120

170

105

2514

1134

120

200

110

2500

1476

120

250



 » Q&A

1/Q: Can you provide OEM ODM SDK CDK service for the all in one interactive flat panel/whiteboard?

A: Yes,well supported.Please consult sales for the specific MOQ



2/Q:Do you have stock?

A: Yes,.Normally, we have a small stock of each size. There will be a batch of stock sold at the bottom price at the end of the quarter and the end of the year. If you have an urgent order during this period, please contact customer service for inventory quantity



3/Q: Is your company a real manufacturer?

A: Yes. Our factories are located in Guangdong Province, Thailand and Vietnam. Guangdong Province China mainly produces smart whiteboards, if you need to see the real factory, please contact us.



4/Q: How is the quality of the product?

A: We have a strict QC process for the material, in house testing, in line inspections and checking before shipment.



5/Q: Does the product only use for school?

A: Smart whiteboards are used in a wide range of scenarios, such as school education, company meetings, hospitals, communities, and so on.



 6/Q: How can I trust your product quality?

A: Products have CE, FCC, CCC and other certifications, factory use ISO90001 and other certifications, a large number of customers give us praise about products and services. Before you buy the product, you can video call with us, we operate the product in real time. After-sales support 1-5 years warranty.



7/Q: What's your after-sale service?

A: 24-hour customer service online, both before and after sales. 1-5 years warranty on replacement parts
