  • End Boring Checkout Lines: Qtenboard StandByMe’s Entertaining Queue Solution
    End Boring Checkout Lines: Qtenboard StandByMe’s Entertaining Queue Solution
    End Boring Checkout Lines: Qtenboard StandByMe’s Entertaining Queue Solution
    End Boring Checkout Lines: Qtenboard StandByMe’s Entertaining Queue Solution
    End Boring Checkout Lines: Qtenboard StandByMe’s Entertaining Queue Solution
    End Boring Checkout Lines: Qtenboard StandByMe’s Entertaining Queue Solution
    End Boring Checkout Lines: Qtenboard StandByMe’s Entertaining Queue Solution
    End Boring Checkout Lines: Qtenboard StandByMe’s Entertaining Queue Solution
  • End Boring Checkout Lines: Qtenboard StandByMe’s Entertaining Queue Solution

    Size:21.5 23.8 27 32inch

    Color:White/Black

    Battery Life:3-9H

1. Dynamic Deal Displays

  • Auto-rotate promotions for last-minute impulse buys (candy, magazines, snacks)

  • Highlight “Manager’s Specials” with countdown timers

2. Entertain & Educate

  • Recipe Shorts: 30-second meal ideas using nearby products

  • Local Trivia: “Did you know? Our honey comes from Smithville Farms, 8 miles away!”

  • Kids’ Cartoons: Reduce restlessness during peak hours

3. Real-Time Alerts

Sync with POS to display:

  • “3 registers opening now!”

  • “Flash sale in Aisle 5 – ends in 15:00!”

  • Recall notices or safety alerts

4. Mobility Advantage

  • Roll between lanes during shift changes

  • Outdoor-capable for curbside pickup queues

  • 3-9 hour battery for power outage resilience

Here’s a concise summary of the three key upgrades in the new Stand By Me TV :

1.Support SIM card

Large screens can be used to communicate with family members.

2.New Privacy Camera Design

The new model features a privacy camera with a physical cover. Users can slide open a plastic shutter to expose the camera only when needed, ensuring privacy protection when inactive.

3,Beige Color Upgrade

The exterior color has been upgraded from pure white (previous model) to a soft beige, offering a gentler visual experience that reduces eye strain.

4,Speaker Relocation

Speakers have been relocated from behind the screen (previous design) to the stand's column structure, improving acoustic projection and delivering significantly louder audio output.


Core Advantages Summary (in these settings):

  • Spatial Freedom: No fixed location required, saves valuable space, enables "plug-and-play" usage.

  • Flexible Viewing: Adjustable gooseneck stand enables multi-angle, multi-height viewing, adapting to various postures and scenarios.

  • Wireless Convenience: Built-in battery eliminates power cord constraints, enabling true portability and rapid deployment.

  • Multi-functional Device: Serves as a high-quality entertainment TV, information display, and digital art piece.

  • Enhanced Experience: Provides entertainment and information in non-traditional TV locations (e.g., beside gym equipment, nursing home beds, hotel bathrooms), significantly improving user (customer, patient, resident, member) experience and satisfaction.

  • Effective Communication: Facilitates information display and visual communication in business, medical, and educational contexts.


Why Choose the Qtenboard Stand By Me TV/ Portable TV?


Product CertificationCE, FCC, RoHS, REACH, CCC, and more
Factory CertificationISO 9001 4001  27001 45001 and more.
Flexible Production LineCustomized sample can be completed within 72 hours, and MOQ=1
Intelligent Quality InspectionAI visual inspection replaces manual work, with a yield rate of 99%


Display ParametersPanel Size23.8"32"
Resolution1920 * 10801920 * 1080
Display Scale16:916:9
Brightness250cd/280cd/
Contrast1200:11200:1
Color8bits-true(16.7M)8bits-true(16.7M)
Maximum Viewing Angle178°178°
Machine ParametersRemote ControlSupport voice remote control(optional)Support voice remote control(optional)
USB 2.0 OTG*1*1
Type_C*1*1
AUX*1*1
HDMI*1(optional)*1(optional)
4G SIM slot*1*1
DC12V-5A*1*1
Front camera800W1300W
MICDual arrayDual array
Audio AmplifierSmart AmplifierSmart Amplifier
SpeakerDual multimedia BOXDual multimedia BOX
Structural partsHardware + PlasticHardware + Plastic
Mechanical buttonsSwitch on/off: Acrylic buttonSwitch on/off: Acrylic button
Gross Weight18KG21KG
Dimensions545 (length) x 325 (height) x 60 (thickness) mm733.76(length) x433.76(height) x 50 (thickness) mm
Lifting rod height1143MM1249.05MM
Base outer diameter400MM430MM
Packing box size1122*466*110MM1190(L) *465.0(w)*235.0(H)MM
System ParametersCPUMTK MT6769(12nm) 2*Cortex-A75 up to 2.0Ghz + 6*Cortex-A55 up to 1.8GhzMTK MT6769(12nm) 2*Cortex-A75 up to 2.0Ghz + 6*Cortex-A55 up to 1.8Ghz
Version13.0 13.0
RAM4GB/8G4G/8G
ROM128G/256G/512G128G/128G
WLAN Function2.4/5GHz WIFI, support WiFi hotspot2.4/5GHz WIFI, support WiFi hotspot
BluetoothBT4.2BT4.2
Language ModeSupports multiple languagesSupports multiple languages
Battery
parameters
Battery Material18650 ternary lithium18650 ternary lithium
Battery charge and discharge times1000 times-capacity retention rate ≥85%1000 times-capacity retention rate ≥85%
Battery specifications (V, A, Wh)11.1V 10000mAh 111Wh14.8V 7800Ma   115W
Charging time3H3H
Battery life4.5H4.5H
Charging Current4.5A4.5A
ChargerPD-Type c chargingPD-Type c charging
Charging indicatorsupportsupport
Wireless chargingNot supportedNot supported
Capacitor ParametersMulti-touchSupports maximum touch points: 10 pointsSupports maximum touch points: 10 points
Number of channels95 channels95 channels
Scan frequencyScan rate and measurement capacitance change: ≥100KHZScan rate and measurement capacitance change: ≥100KHZ
Wake-up response time msTime from finger touch to response: 15msTime from finger touch to response: 15ms
Touch accuracy mmDeviation between actual position and touch reflected position: ±2.0mmDeviation between actual position and touch reflected position: ±2.0mm
LinearityDeviation of straight line touch: ±2.0mmDeviation of straight line touch: ±2.0mm
Touch separation mmThe distance between two points that can be distinguished: 15mmThe distance between two points that can be distinguished: 15mm
SensitivityTouch screen sensitivity (click≤φ6mm, slip≤φ6mm: uniformly≤1.5mm)Touch screen sensitivity (click≤φ6mm, slip≤φ6mm: uniformly≤1.5mm)
Temperature rangeWorking temperature: -10~60Working temperature: -10~60
Operating voltageDC5VDC5V
Working power consumption≥1W≥1W
Mobile Display Rack ParametersFront and rear elevation angle: (°)15°20°
Lifting range (cm)12CM20CM
Rotation angle (°)90°180°
Shaft life≥3000 spins≥3000 spins
Guide rail life≥5000≥3000
3D Accelerated Gravitysupportsupport
Gyroscopesupportsupport
AccessoryData cableType-c data cable(Optional)Type-c data cable(Optional)
Remote ControlQuantity: 1(Optional)Quantity: 1(Optional)
Power adapterQuantity: 19V/3.8AQuantity: PD-87W, Type-c adapter
Capacitive stylusQuantity: 1 piece(Optional)Quantity: 1 piece(Optional)
Mobile cartQuantity: 1 setQuantity: 1 set
