  • OEM Big size 86 inch 4k uhd android wifi hanging wall mounted lcd screen digital signage outdoor advertising media player

    Brand: QUNMAO

    Model: QM-8618HW-L

    Screen Size: 86inch

    Resolution: 1920*1080/3840*2160(Optional)

    Angle of view: 178°/178°

    Contrast ratio: 4000:01:00

    Display size: 1899(H) x 1066(V)mm

    Display rate: 16:09

    Back light: LED

    Brightness: ≥2500cd/㎡

    Refresh rate: 60HZ

    Color: 16.7M(8-bit)

    Operation system: Android 13.0

OEM Big size 86 inch 4k uhd android wifi hanging wall mounted lcd screen digital signage outdoor advertising media player


China Qunmao is a leading supplier of indoor/outdoor touch screen LCD digital signage and advertising displays. We offer high-quality advertising media machines at competitive prices. As certified commercial video advertising player product manufacturers, suppliers, wholesalers and factories, we provide a comprehensive range of services to meet our clients' diverse needs.


Wall-Mounted Outdoor Digital Signage

Different Size: 13.3/18.5/21.5/23.6/27/32/43/49/55/65/75/86/98 inch Screen can support


Vertical Stand Outdoor Digital Signage

Different Size: 32/43/49/55/65/75/86 inch Screen can support


Digital signage Product Description


1.Structural design: the shell is made of 1.0-2.5mm high-quality galvanized sheet, sprayed with outdoor special powder, and the outdoor anti-corrosion is more than 7 years.

2.Waterproof design: the shell structure is designed with waterproof groove and waterproof labyrinth of air inlet and outlet holes, meeting the protection level of IP65.

3.Dustproof design: The air inlet and outlet are designed with special dust-proof filter (medium and high efficiency dust-proof filter) to filter the fine dust in the air and prevent mosquitoes from entering the device.

4.Anti riot glass: 6mm high permeability fully tempered glass is used as the protective tempered glass in front of the screen of the whole machine, with the light transmission coefficient > 95%.

5.Anti theft design: equipped with anti-theft door lock (padlock can be added, double anti-theft) to truly achieve anti-theft security. The fixing method is to fix the bottom expansion screw or embedded parts.

6.High brightness, with air cooling system, and multi split screen display mode.


What is Outdoor wall mount advertising digital signage?


Outdoor wall-mounted digital signage refers to a type of electronic display screen that is mounted on an exterior wall of a building or structure for the purpose of advertising and marketing. These digital signs are typically large in size and high-resolution, allowing for vivid and dynamic content to be displayed to passers-by and potential customers. Outdoor wall-mounted digital signage is used by businesses and organisations to promote their products, services, events, and brand messages in a visually appealing and attention-grabbing way. These signs are often equipped with features such as remote content management, weatherproof casing, and sunlight readability to ensure visibility and durability in outdoor environments.


86 inch wall-mount outdoor Digital signage Description



BrandQUNMAO
ModelQM-8618HW
Screen Size86inch
Resolution1920*1080/3840*2160(Optional)
Angle of view178°/178°
Contrast ratio4000:01:00
Display size1899(H) x1066(V)mm
Display rate16:09
Back lightLED
Brightness≥2500cd/㎡
Refresh rate60HZ
Color16.7M(8-bit)
Response time6ms
Life span50000h
Smart photosensitiveThe intensity of outdoor light automatically adjusts the brightness of the LCD display screen
TechnologyCapacitive touch
Touch point20 points
Touch modeFinger or touch pen
Touch accuracy≦2mm
Service life60 Million touch
Drive modeDriver-free
Camera500MP
Operation systemAndroid
Version13
CPUT972 Quad core A55,Main frequency up to 1.9GHz
GPUMali-G31
RAM2GB
Storage memory16GB
InterfaceHDMI*1(2.1 4kx2k@60Hz input) USB*2
Audio interface3.5mm ear jack*1
Network1pc,10M/100M Adaptive Ethernet
WIFI、BTBuilt in WIFI(2.4G single-signal),BT4.2
3G/4GChoose to install
Decoding CapabilitySupports 4K video and picture decoding and playback
Software applicationSupport to install the third-party software
LanguageRussian、English etc language
Boot AnimationSupport to customize
Infrared remote controlOperate system by remote control
Audio functionSupport left/right channel output,built-in double 8Ω/15W power amplifier
Power-on/offRemote control/timing/network wake-up/self-start
System authorizationAllow root permission and customize software development
Mouse modesupport wired/wireless mouse or use keyboard




We support customized product service if you want it!

>>>Please send us an inquiry<<<


Digital signage Application



Our digital signage products are designed to reach media outlets and deliver content to large screens. They are suitable for a range of applications, including airports, financial institutions, shopping malls, supermarkets, public spaces, government buildings, hotels, offices, and advertising.


OEM Big size 86 inch 4k uhd android wifi lcd screen digital signage outdoor advertising media player (12).jpg


86 inch wall-mount outdoor Digital signage Technical specifications



Screen Size86inch
System updateSupport local and remote upgrade

Audio:MP3,WMA,WAV, APE, FLAC, AAC, OGG,M4A,3GPP etc
Play modePicture:JPG、BMP、PNG etc

Video:AVI,rm,rmvb, MKV,WMV,MOV,MP4 etc
TypingStandard Android keyboard as default,can install the third party typing
More functionsfollow instruction manual/video or contact supplier
Background supportWeb/mobile IE(local network/WAN)
Play modeNetworking/standalone
Play supportvideo、picture、subtitles、PPT、web、weather、clock etc mixture to play
Smart splicingsupport custom playing modes to splice as setting
Timing functionsupport to set playing custom program in time period
Terminal administrationAdministrator can create and modify account for level-to level
 administration
More functionfollow instruction manual/video or contact supplier
Colorblack white
Body MaterialUsing 1.2-2.5mmSGCC high-quality galvanized steel plate
Protection gradeIP65
Protective glass6mm explosion-proof glass (AG anti-glare/AR anti-ultraviolet optional)
Cooling by designIntelligent direct ventilation (forced air cooling) heat dissipation system
Energy savingIntelligent temperature control cooling system automatically adjusts wind speed and volume
Dust proofHigh-precision filtration system blocks 99% of dust particles
Product size2140*1340*180mm
Packing size2220*325*1420mm
BracketUniversal for horizontal/vertical hanging
Packing materialCarton
Net/gross weight200KG/202KG
Install waysmount-on wall/embedding/hang/bracket
Scenariosoutdoor
Rated VoltageAC 100V-240V
Rated power≦500W-1500W
Suitable Environment-20℃ to +55℃ outdoor environment operation
Time switchSupport 16 groups of timed on/off, repeatable settings, timed on/off by day, week, month
Lightning protectionLevel 3
Leakage protection switchDisconnect the circuit promptly when leakage occurs
